● Two modes settings-Rotary drilling & hammer only with idle position;

● Chiseling angle adjustable by 12-steps lock; enabling you to adapt it to each work situation (e.g. when using tile chisels)

● Anti-Vibration System, to reduced fatigue ;

● Trigger switch and Ergonomic handle with soft grip;

● 6-steps setting wheel and constant Speed Control for variable adjustment of the speed and impact rate for optimum performance ;

● Indicator of power supply;

● Indicator of Carbon Brush maintenance;

● Low vibration & noise design with high impact energy;

● 360°Auxiliary handle;

● Safety clutch device;

● Hammer lock function

Technical Specification

Rated Voltage (V~)	220-240 / 120
Frequency (Hz)	50 / 60
Rated Input (W / AMPS）	1700/15
No load Speed (rpm）	100-220
Impact rate at rated speed (bpm)	1000-2150
Impact Energy (J)	5-19/3.7-14 Ft/lbs
Tool holder	SDS-Max

Drilling Capacity

Max. Drilling dia. concrete (mm)	Φ55
Optimum. appl. range concrete (mm)	Φ25mm-Φ50mm
Max. dia. concrete core cutters(mm)	Φ150mm/Φ6”

Weight (kg) (based on EPTA)	12/26.4lbs
Size (mm)	613x348x123 / 24”x13.7”x4.8”
