● Two modes settings-Rotary drilling & hammer only with idle position;

● Chiseling angle adjustable by 12-steps lock; enabling you to adapt it to each work situation (e.g. when using tile chisels)

● Anti-Vibration System, to reduced fatigue ;

● Trigger switch and Ergonomic handle with soft grip;

● 6-steps setting wheel and constant Speed Control for variable adjustment of the speed and impact rate for optimum performance ;

● Indicator of power supply;

● Indicator of Carbon Brush maintenance;

● Low vibration & noise design with high impact energy;

● 360°Auxiliary handle;

● Safety clutch device;

● Hammer lock function

Technical Specification

Rated Voltage (V~)	220-240 / 120
Frequency (Hz)	50 / 60
Rated Input (W / AMPS）	1500/14
No load Speed (rpm）	150/305
Impact rate at rated speed (bpm)	1380-2760
Impact Energy (J)	2-15
Tool holder	SDS-Max

Drilling Capacity

Max. Drilling dia. concrete (mm)	Φ52
Optimum. appl. range concrete (mm)	Φ20mm-Φ45mm
Max. dia. concrete core cutters(mm)	Φ125mm

Weight (kg) (based on EPTA)	9
Size (mm)	560x280x112

Auxiliary handle	(ID 88263205）
Carbon brush	(ID 88244081.1 for 220V）/(ID 88244081.2 for 120V）
Spare grease tube	(ID 88304012 for 30g）
Carrying case	(ID 88302054 IMC /Metal locker/Plastic locker)/(ID 88302070 BMC)
