ID NO.: 01.02.0062
MODEL NO.: PR4-28PA
SIMKO TOOLS IS ONE OF THE TOP POWER TOOLS MANUFACTURERS IN CHINA
SIMKO TOOLS HAVE MORE THAN 10 YEARS' MANUFACTURING AND R&D EXPERIENCE
● Two modes settings-Rotary drilling & hammer only ;
● Chiseling angle adjustable by 8-steps lock; enabling you to adapt it to each work situation (e.g. when using tile chisels)
● Anti-Vibration System, to reduced fatigue ;
● Trigger switch and Ergonomic handle with soft grip;
● 3-steps setting Speed ；
● Indicator of power supply;
● 360°Auxiliary handle;
● Safety clutch device;
| Rated Voltage (V~) | 220-240 / 120 |
| Frequency (Hz) | 50 / 60 |
| Rated Input (W / AMPS） | 1020/8 |
| No load Speed (rpm） | 520/770/920 |
| Impact rate at rated speed (bpm) | 2250/3320/3970 |
| Impact Energy (J) | 3.5 |
| Tool holder | SDS-Plus |
| Max. Drilling dia. concrete (mm) | Φ28 |
| Optimum. appl. range concrete (mm) | Φ8mm-Φ18mm |
| Max. dia. concrete core cutters(mm) | Φ50mm |
| Weight (kg) (based on EPTA) | 4.5 |
| Size (mm) | 378×244×100 |
| Unit Quantity (pcs) | 3 |
| Auxiliary handle | (ID 26.02.0357） |
| Depth stopper | (ID 26.02.0385） |
| Carbon brush | (ID 24.03.0195 for 220V）/(ID 24.03.0196 for 120V） |
| Spare grease tube | (ID 30.12.0001 for 30g） |
| Carrying case | (ID 30.03.0695 BMC) |
