ID NO.: 01.01.0085
MODEL NO.: PH6-17HA
SIMKO TOOLS IS ONE OF THE TOP POWER TOOLS MANUFACTURERS IN CHINA
SIMKO TOOLS HAVE MORE THAN 10 YEARS' MANUFACTURING AND R&D EXPERIENCE
● Chiseling angle adjustable by 12-steps lock; enabling you to adapt it to each work situation (e.g. when using tile chisels)
● Anti-Vibration System, reduced fatigue
● Lock-on switch and Ergonomic handle with soft grip;
● 6-steps setting wheel and constant Speed Control for variable adjustment of the speed and impact rate for optimum performance ;
● Indicator of power supply;
● Indicator of Carbon Brush maintenance;
● Low vibration & noise design with high impact energy;
● 360°Auxiliary handle;
| Rated Voltage (V~) | 230 / 120 |
| Frequency (Hz) | 50 / 60 |
| Rated Input (W / AMPS） | 1200 / 10 |
| Impact rate (bpm) (/min) | 3100 |
| Impact Energy (J) | 20 |
| Tool holder | SDS-Max |
| Weight (kg) (based on EPTA) | 6 |
| Size (mm) | 475×244×95 |
| Unit Quantity (pcs) | 1 |
| Size (mm) | 595x157x430 |
| G.W./N.W.(kg) | 15.5/14.5 |
| Loading QTY in 20ft container | 720 |
| Auxiliary handle | (ID 26.02.0353） |
| Carbon brush | (ID 24.03.0124 for 220V）/(ID 24.03.0125 for 120V） |
| Spare grease tube | (ID 30.12.0001 for 30g） |
| Tine Chisel | (ID 02.01.0002）;17x280mm（HEX） |
| Flat Chisel | (ID 02.01.0003）;17x280mm（HEX） |
| Carrying case (Spare part No) | (ID 88302051 BMC-US style)/(ID 88302057 BMC-RU style) |
