ID NO.: 01.01.0090
MODEL NO.: PH5-18MA
SIMKO TOOLS IS ONE OF THE TOP POWER TOOLS MANUFACTURERS IN CHINA
SIMKO TOOLS HAVE MORE THAN 10 YEARS' MANUFACTURING AND R&D EXPERIENCE
● Anti-Vibration System, reduced fatigue
● Lock-on switch and Ergonomic handle with soft grip;
● Low vibration & noise design with high impact energy;
● 360°Auxiliary handle;
● Indicator of power supply;
● Chiseling angle adjustable by 12-steps lock; enabling you to adapt it to each work situation (e.g. when using tile chisels)
| Rated Voltage (V~) | 230 / 120 |
| Frequency (Hz) | 50 / 60 |
| Rated Input (W / AMPS） | 1200 / 10 |
| Impact rate (bpm) (/min) | 3100 |
| Impact Energy (J) | 14 |
| Tool holder | SDS-Max |
| Weight (kg) (based on EPTA) | 5.6 |
| Size (mm) | 489x244x95 |
| Unit Quantity (pcs) | 2 |
| Size (mm) | 555x337x380 |
| G.W./N.W.(kg) | 20.1/19.1 |
| Loading QTY in 20ft container | 860 |
| Auxiliary handle | (ID 26.02.0353） |
| Carbon brush | (ID 24.03.0124 for 220V）/(ID 24.03.0125 for 120V） |
| Spare grease tube | (ID 30.12.0001 for 30g） |
| Tine Chisel | (ID 02.01.0033);Φ18×350mm（SDS-Max） |
| Flat Chisel | (ID 02.01.0034);Φ18×350mm（SDS-Max） |
| Carrying case (Spare part No) | (ID 88302051 BMC-US style)/(ID 88302057 BMC-RU style) |
