● Two modes settings-Rotary drilling & hammer only with idle position;

● Chiseling angle adjustable by 12-steps lock; enabling you to adapt it to each work situation (e.g. when using tile chisels)

● Anti-Vibration System, to reduced fatigue ;

● Trigger switch and Ergonomic handle with soft grip;

● 6-steps setting wheel and constant Speed Control for variable adjustment of the speed and impact rate for optimum performance ;

● Indicator of power supply;

● Indicator of Carbon Brush maintenance;

● Low vibration & noise design with high impact energy;

● 360°Auxiliary handle;

● Safety clutch device;

● Grease Lubrication

Technical Specification

Rated Voltage (V~)	220-240 / 120
Frequency (Hz)	50 / 60
Rated Input (W / AMPS）	1200/11.5
No load Speed (rpm）	235-514
Impact rate at rated speed (bpm)	1350-2950
Impact Energy (J)	2-10
Tool holder	SDS-Max

Drilling Capacity

Max. Drilling dia. concrete (mm)	Φ42
Optimum. appl. range concrete (mm)	Φ18mm-Φ32mm
Max. dia. concrete core cutters(mm)	Φ90mm

Weight (kg) (based on EPTA)	6.52/14.4Lb
Size (mm)	486x260x117 /19"x10"x4.6”

Auxiliary handle	(ID 26.01.0391）
Depth stopper	(ID 22.02.0015）
Carbon brush	(ID 24.03.0124 for 220V）/(ID 24.03.0125 for 120V）
Spare grease tube	(ID 30.12.0001 for 30g）
Carrying case	(ID 30.03.0594 BMC)/ (ID 30.03.0472 Metal locker/ 30.03.0483 Plastic locker IMC)
