● Two modes settings-Rotary drilling & hammer only with idle position;

● Chiseling angle adjustable by 12-steps lock; enabling you to adapt it to each work situation (e.g. when using tile chisels)

● Anti-Vibration System, to reduced fatigue ;

● Trigger switch and Ergonomic handle with soft grip;

● 6-steps setting wheel and constant Speed Control for variable adjustment of the speed and impact rate for optimum performance ;

● Indicator of power supply;

● Indicator of Carbon Brush maintenance;

● Low vibration & noise design with high impact energy;

● 360°Auxiliary handle;

● Safety clutch device;

Technical Specification

Rated Voltage (V~)	220-240 / 120
Frequency (Hz)	50 / 60
Rated Input (W / AMPS）	1100/10
No load Speed (rpm）	300-760
Impact rate at rated speed (bpm)	1950-4860
Impact Energy (J)	1-7
Tool holder	SDS-Max

Drilling Capacity

Max. Drilling dia. concrete (mm)	Φ35
Optimum. appl. range concrete (mm)	Φ16mm-Φ28mm
Max. dia. concrete core cutters(mm)	Φ90mm

Weight (kg) (based on EPTA)	6.14/13.5LB
Size (mm)	456x264x105/17.9"X10.4"X4.1"

Auxiliary handle	(ID 26.01.0391）
Depth stopper	(ID 22.02.0093）
Carbon brush	(ID 24.03.0124 for 220V）/(ID 24.03.0125 for 120V）
Spare grease tube	(ID 30.12.0001 for 30g）
Carrying case	(ID 30.03.0571 BMC)/ID 30.03.0406 Metal locker/ ID 30.03.0417 Plastic locker IMC )
